Product Description
The Series VF Visi-Float® VFA-27-SS Acrylic Flowmeter provides dependable 10–100 LPM air measurement in systems requiring stainless steel wetted materials for chemical compatibility or clean-air service.
This measurement-only configuration is ideal for analyzer enclosures, cabinet purge systems, laboratory panels, and OEM instrumentation where upstream regulators or controllers already manage flow. Its clear acrylic housing allows immediate visual verification, while the precision-machined tapered bore ensures stable float positioning and repeatable readings across the operating range.
Built for panel mounting in vertical installations, the VFA-27-SS integrates easily into new builds or retrofit replacements—delivering long-term durability in industrial and process environments.
WHY ENGINEERS SPECIFY THIS MODEL
• Stainless steel wetted flow path for compatibility
• 10–100 LPM air measuring range
• Compact 2" scale
• Measurement-only design for controlled systems
• High-visibility acrylic body
• OEM-ready panel mounting
• RoHS compliant
• Analyzer- and purge-system ready
TYPICAL APPLICATIONS
• Analyzer cabinets
• Cabinet purge systems
• Laboratory airflow monitoring
• Environmental sampling panels
• OEM instrumentation skids
• Pilot plants
• Process air systems
KEY TECHNICAL SPECIFICATIONS
Flow Range: 10–100 LPM Air
Scale: 2"
Valve: None
Mounting: Vertical
Process Connection: 1/8" FNPT
Accuracy: ±5% FS
Body: Acrylic
Wetted Materials: Stainless Steel
Pressure Rating: 100 psig
Compliance: RoHS II
