Product Description
-15 to 0 PSI Digital Pressure Gage – Series DPG-000
The Series DPG-000 Digital Pressure Gage is engineered for vacuum and low-pressure applications requiring dependable accuracy, rugged construction, and fast digital verification. Featuring ±0.5% full-scale accuracy, NEMA 4X housing, and a bright 4-digit backlit display, this gage eliminates parallax errors common with analog instruments.
Battery powered with automatic shut-off and push-button zeroing, the DPG-000 is ideal for field service, OEM installations, and process monitoring where precision and portability matter.
Pressure Range, Accuracy & Construction
-
Pressure Range: -15 to 0 PSI
-
Accuracy: ±0.5% F.S.
-
Optional Accuracy: ±0.25% F.S.
-
Enclosure: NEMA 4 / 4X (IP66)
-
Housing: Anodized aluminum with polycarbonate covers
-
Wetted Materials: 316L Stainless Steel
-
Sensor: 316L SS
-
Seals: Buna-N O-rings
-
Process Connection: 1/4" Male NPT
Display & Power System
-
Display: 4-digit LCD (.425" H)
-
Backlight: Push-button
-
Power: (2) AAA alkaline batteries (included)
-
Battery Life: 2000 hours typical
-
Low Battery Indicator: Yes
-
Auto Shut-Off:
-
Gage: 60 minutes (disengageable)
-
Backlight: 2 minutes
-
Applications
-
Vacuum monitoring
-
Process systems
-
OEM equipment
-
Analog gage replacement
-
Gas calibration setups
-
Industrial compliance testing
-
Combustible gas service
-
Liquid pressure measurement
Why Choose the Series DPG Digital Pressure Gage?
-
High-accuracy sensing prevents out-of-spec operation
-
Digital display eliminates reading errors
-
Battery operation reduces wiring and downtime
-
Push-button zero speeds installation
-
Rugged NEMA 4X housing for harsh environments
-
Portable design for field verification
Technical Specifications
-
Pressure Limit:
-
2× range ≤1000 PSI
-
5000 PSI (3000 PSI range)
-
7500 PSI (5000 PSI range)
-
-
Operating Temp: 0–130°F
-
Temperature Effect:
-
32–70°F: 0.026%/°F
-
0–32°F: 0.09%/°F
-
0–10°F: 0.50%/°F
-
-
Size: 3.00" OD × 1.90" deep
-
Weight: 8.84 oz
Agency Approvals
-
CE
-
FM Intrinsically Safe (select models in series)
Shipping Information
Ships in 1–2 business days, subject to availability.
